V1 M

DAW Controller

Improve Your Production
Workflow, Customize Your Control

FEATURES:

  • 9x touch-sensitive motorized faders with 12-bit resolution
  • Large, programmable 7 inch, 24 panel digital touch screen display showing DAW functions per 5 color modes – a potential total of 120 displayable and actionable functions
  • Organize DAW functions in the 24 panel touchscreen easily via ‘drag and drop’ in the iMAPTM – changes made in real time
  • Capability of connecting to 3 DAWs at one time via the DAW select buttons
  • Extremely hardwearing, durable and versatile
  • Onboard 2 inch TFT display showing channel name, control values, channel colors etc., (DAW dependent)
  • Attractive, modern meter bridge, featuring precise, clear and eye-catching LED meters
  • Additional lower 1.14 inch TFT display for each channel (some DAWs are equipped to display additional information on this screen)
  • Extremely high quality, large optical encoder jog wheel with very precise, smooth control for fast search, scrub etc.
  • 8 smooth action dual-function encoder knobs (Rotate and Enter)
  • 2-segment LED display shows timecode or location of your project in either SMPTE or beat clock (bars:beats:ticks) formats
  • Illuminated function buttons for ‘Read’, ‘Write’, ‘Touch’, ‘Latch’, ‘Trim’; and ‘Off’ – activated/deactivated as required per DAW
  • Illuminated buttons for channel control including Mute, Solo and Record
  • 6 illuminated transport buttons including Play, Stop, Record, Rewind, Fast Forward and Loop
  • Dedicated ‘Master/Assign’ button for quick switching the Master fader from the master channel to a pre-designated track
  • Illuminated “Zoom” button with 2 d directional keys (Left/Right & Up/Down), also used in combination with the jog wheel
  • Illuminated ‘Focus’ button which allows the user to “focus” in and adjust plug-in, EQ parameters etc. via the smooth-action jog wheel
  • 2 illuminated “Track” buttons for selecting individual channels
  • 2 illuminated “Bank” buttons for shifting 8-channels at a time
  • Supports Universal Mackie Control and HUI protocols for seamless integration with compatible music production software
  • Supports Ability, Audition, Ableton Live, Bitwig, Cakewalk, Cubase/Nuendo, Digital Performer, FL Studio, Mixbus 32C, Pro Tools, Logic Pro, Luna, Reaper, Reason, Samplitude, Studio One and Tracktion Waveform
  • iMapTM software downloadable from the product page
  • USB C high-speed connectivity
  • Firmware upgrade available via USB C connection and iMap TM software
  • User A & User B 1/4 inch inputs for connecting footswitch pedals
  • Class-compliant with MacOS 10.15 or above & Windows 10 or above
  • Superior build quality and robust metal casing with Kensington lock port

NameSpec
ConnectorTo computer: USB connector (standard type)
Power supply 12V2.5A DC (Outside negative inside positive)
Current consumption 2.5Aor less
Weight5.6kg (12.3lb)
Dimensions 485(W) x384.5(D) x 178(H)mm
Dimensions 19.09”(W) x 15.14”(D) x 7”(H)

V1 M

The future of DAW controllers has just arrived

FEATURES:

  • 9x touch-sensitive motorized faders with 12-bit resolution
  • Large, programmable 7 inch, 24 panel digital touch screen display showing DAW functions per 5 color modes – a potential total of 120 displayable and actionable functions
  • Organize DAW functions in the 24 panel touchscreen easily via ‘drag and drop’ in the iMAPTM – changes made in real time
  • Capability of connecting to 3 DAWs at one time via the DAW select buttons
  • Extremely hardwearing, durable and versatile
  • Onboard 2 inch TFT display showing channel name, control values, channel colors etc., (DAW dependent)
  • Attractive, modern meter bridge, featuring precise, clear and eye-catching LED meters
  • Additional lower 1.14 inch TFT display for each channel (some DAWs are equipped to display additional information on this screen)
  • Extremely high quality, large optical encoder jog wheel with very precise, smooth control for fast search, scrub etc.
  • 8 smooth action dual-function encoder knobs (Rotate and Enter)
  • 2-segment LED display shows timecode or location of your project in either SMPTE or beat clock (bars:beats:ticks) formats
  • Illuminated function buttons for ‘Read’, ‘Write’, ‘Touch’, ‘Latch’, ‘Trim’; and ‘Off’ – activated/deactivated as required per DAW
  • Illuminated buttons for channel control including Mute, Solo and Record
  • 6 illuminated transport buttons including Play, Stop, Record, Rewind, Fast Forward and Loop
  • Dedicated ‘Master/Assign’ button for quick switching the Master fader from the master channel to a pre-designated track
  • Illuminated “Zoom” button with 2 d directional keys (Left/Right & Up/Down), also used in combination with the jog wheel
  • Illuminated ‘Focus’ button which allows the user to “focus” in and adjust plug-in, EQ parameters etc. via the smooth-action jog wheel
  • 2 illuminated “Track” buttons for selecting individual channels
  • 2 illuminated “Bank” buttons for shifting 8-channels at a time
  • Supports Universal Mackie Control and HUI protocols for seamless integration with compatible music production software
  • Supports Ability, Audition, Ableton Live, Bitwig, Cakewalk, Cubase/Nuendo, Digital Performer, FL Studio, Mixbus 32C, Pro Tools, Logic Pro, Luna, Reaper, Reason, Samplitude, Studio One and Tracktion Waveform
  • iMapTM software downloadable from the product page
  • USB C high-speed connectivity
  • Firmware upgrade available via USB C connection and iMap TM software
  • User A & User B 1/4 inch inputs for connecting footswitch pedals
  • Class-compliant with MacOS 10.15 or above & Windows 10 or above
  • Superior build quality and robust metal casing with Kensington lock port

NameSpec
ConnectorTo computer: USB connector (standard type)
Power supply 12V2.5A DC (Outside negative inside positive)
Current consumption 2.5Aor less
Weight5.6kg (12.3lb)
Dimensions 485(W) x384.5(D) x 178(H)mm
Dimensions 19.09”(W) x 15.14”(D) x 7”(H)

V1 M

The V1-M is a powerful DAW controller that gives you tactile control of your Digital Audio Workstation helping you streamline your workflow and get your projects done faster. Here are some of the features that will make the V1-M work for you:

  • Hands On Control: The V1-M has 8 channels of motorized faders, which can be expanded up to 64 channels (depending on your DAW) with the addition of optional V1-X DAW Control Expanders. This gives you plenty of control over your mix, even if you’re working on a complex project.
  • Customizable Touchscreen: The V1-M has a large customizable touchscreen display with 5 color coded layers of commands that can be used to control your DAW and match your specific workflow. This makes it easy to quickly access the controls you need, without having to take your eyes off the mix.
  • OLED Display and Meter Bridge: The large OLED display and meter bridge show the current levels, pan positions, and other information. This makes it easy to see what’s going on with your mix, even if you’re not looking at the computer monitor.
  • Integration with popular DAWs: The V1-M is compatible with a wide range of popular DAWs, including Bitwig, Cubase/Nuendo, Logic Pro X, Ableton Live, and Pro Tools. Additionally, you can run up to 3 DAWs at one time with no interruption to your workflow.

V1 M

The V1-M is a powerful DAW controller that gives you tactile control of your Digital Audio Workstation helping you streamline your workflow and get your projects done faster. Here are some of the features that will make the V1-M work for you:

  • Hands On Control: The V1-M has 8 channels of motorized faders, which can be expanded up to 64 channels (depending on your DAW) with the addition of optional V1-X DAW Control Expanders. This gives you plenty of control over your mix, even if you’re working on a complex project.
  • Customizable Touchscreen: The V1-M has a large customizable touchscreen display with 5 color coded layers of commands that can be used to control your DAW and match your specific workflow. This makes it easy to quickly access the controls you need, without having to take your eyes off the mix.
  • OLED Display and Meter Bridge: The large OLED display and meter bridge show the current levels, pan positions, and other information. This makes it easy to see what’s going on with your mix, even if you’re not looking at the computer monitor.
  • Integration with popular DAWs: The V1-M is compatible with a wide range of popular DAWs, including Bitwig, Cubase/Nuendo, Logic Pro X, Ableton Live, and Pro Tools. Additionally, you can run up to 3 DAWs at one time with no interruption to your workflow.
Play Video

iMAP is a powerful tool that helps you to get the most out
of your V1-M. It's easy to use and it's packed with
features and advanced functionality.


iMAP is a powerful tool that helps you to get the most outof your V1-M. It’s easy to use and it’s packed withfeatures and advanced functionality.

Recording and Mixing

The V1-M’s motorized faders and touchscreen display make it easy to navigate through large sessions. You can quickly zoom in and out of the session, and you can easily see the levels and pan positions of your tracks with the large OLED screen and meter bridge. This allows you to use your ears for recording and mixing, not your mouse.

Content Creation

You can use the faders, knobs, buttons and touchscreen to adjust the levels, pan positions, and other parameters of your tracks. Customizable control means you can put your most used commands right where you want them helping you create engaging content quickly and efficiently.​

Music Production

The V1-M can help you to stay creative. The touchscreen display and motorized faders give you a tactile experience that can help you to feel more connected to your music. The V1-M’s customizable controls also allow you to set up your controller the way that works best for you.​

Post Production and Sound Design

The V1-M is expandable and flexible. Depending on your DAW, you can add up to 64 channels to your setup. This can be especially helpful when you’re working on a complex project with a lot of dialogue tracks or foley sounds, or if you’re designing lush soundscapes or creating new worlds.

Recording and Mixing

The V1-M’s motorized faders and touchscreen display make it easy to navigate through large sessions. You can quickly zoom in and out of the session, and you can easily see the levels and pan positions of your tracks with the large OLED screen and meter bridge. This allows you to use your ears for recording and mixing, not your mouse.

Content Creation

You can use the faders, knobs, buttons and touchscreen to adjust the levels, pan positions, and other parameters of your tracks. Customizable control means you can put your most used commands right where you want them helping you create engaging content quickly and efficiently.​

Music Production

The V1-M can help you to stay creative. The touchscreen display and motorized faders give you a tactile experience that can help you to feel more connected to your music. The V1-M’s customizable controls also allow you to set up your controller the way that works best for you.​

Post Production and Sound Design

The V1-M is expandable and flexible. Depending on your DAW, you can add up to 64 channels to your setup. This can be especially helpful when you’re working on a complex project with a lot of dialogue tracks or foley sounds, or if you’re designing lush soundscapes or creating new worlds.

V1-X DAW Control Expander
Expand your V1-M to 16, 32, or even 64 channels depending on your DAW with the V1-X DAW Control Expander.
Each V1-X houses eight touch-sensitive motorized channel faders with 12-bit resolution, eight dual function encoder knobs, mute, solo,
select and record buttons, plus an OLED display showing channel names and different control parameters for each
channel. It also includes LED level meter bridge in a robust metal casing and a second LCD
display. (Expandability is totally dependent on your Digital Audio Workstation. Please consult your
DAW's manual to determine how many extenders your DAW allows.)

V1-X DAW Control Expander

Expand your V1-M to 16, 32, or even 64 channels depending on your DAW with the V1-X DAW Control Expander. Each V1-X houses eight touch-sensitive motorized channel faders with 12-bit resolution, eight dual function encoder knobs, mute, solo, select and record buttons, plus an OLED display showing channel names and different control parameters for each channel. It also includes LED level meter bridge in a robust metal casing and a second LCD display. (Expandability is totally dependent on your Digital Audio Workstation. Please consult your DAW’s manual to determine how many extenders your DAW allows.)

Plugin Bundles

Plugin Bundles

What’s in the package?

· V1 M Master MIDI Control Surface
· Type C USB Cable
· External Power Adapter
· Quick Start Guide

What’s in the package?

  • V1 M Master MIDI Control Surface
  • Type C USB Cable
  • External Power Adapter
  • Quick Start Guide
