G-Board
- 8 robust metal click type foot switches
- Ideal for guitarists
- Extremely compact and compatible with MacBookTM
- Class-compliant with Windows XP, Vista (32 bit / 64 bit), and Mac OS X
- USB bus-powered
- 2xUSB Connectors for daisy chain with other i-series controller
- Available in Black and White
- iCover (optional) – Aluminum cover is available in assorted colors
- Custom laser-engraving service for aluminum cover is available at on-line purchase (optional)
- Bitwig 8Track included
- Dotec audio plugins included
- Tracktion DAW Essentials Collection plugins included
- Kilohearts Toolbox plugins included
- Harrison 32c Vocal Intensity Processor plugin included
Name | Spec |
Connector | To computer:USB connector (mini B type) |
Connector | To i-series controller:USB connector (standard type) |
Power supply | USB bus power |
Current consumption | 100mA or less |
Weight | 0.77kg (1.7lb) |
Dimensions | 325(L) X 99(W) X 20(H) mm |
Dimensions | 12.78"(L) x 3.78"(W) x 0.75"(H) |
- Setup procedure illustration - Cubase/Nuendo
- Setup procedure illustration - Pro Tools
- Setup procedure illustration - Logic Pro
- Setup procedure illustration - Abelton Live
- Setup procedure illustration - Samplitude
- Setup procedure illustration - Reason
- Setup procedure illustration - Reaper
- Setup procedure illustration - Studio One
- Supports Intel, M1, M1 Max, M1 Pro, M1 Ultra, M2 and AMD processors
- (Firmware is recognized on M1 Max, M1 Pro, M1 Ultra and M2 and AMD CPUs, however, you can only use Intel or M1 CPU to perform firmware update procedure)
- Mac OS X 10.11 El Capitan to Mac OS 13 Ventura
- iOS 11 - iOS 14
- Windows 7 - 11
