• 2 x 2 analog balanced I/O
    ● Dual microphone/instrument preamps with gain controls, LED metering, phantom power and input gain
  • Two analog outputs on 1/4″ TRS jacks
  • S/PDIF I/O on RCA coaxial connectors
  • Supports sampling rates from 44.1Hz to 192KHz
  • Headphone output with assignable source and individual volume control
  • Hardware Direct / PC Monitoring Adjustment knob
  • Supports Direct Sound, WDM, ASIO and GIGA studio
  • Compatible with Mac OSX (Intel CPU) and Windows XP, Vista (32bits), Windows 7 (32-bit/64-bit), Windows 8 (32-bit/64-bit)
  • Full duplex, simultaneous record/playback
  • Rugged aluminum construction


Mic/Inst Inputs 1/2 (Balanced; at Minimum Gain)
Frequency Response22Hz to 22kHz (+/-0.1dB)
Dynamic Range100dB, A-weighted
Signal-to-Noise Ratio-100dB, A-weighted
THD+N<0.0061% (-90dB)
Crosstalk-100dB @ 1kHz
Maximum Input level-3.8dBu, typical
Input ImpedanceInst in: 500K Ohms, typical
Input ImpedanceMic in: 1.8K Ohms, typical
Adjustable Gain> 50dB
Total Gain Range+45dB
Line Outputs 1-2 (TRS)
Frequency Response22Hz to 22kHz (+/-0.1dB)
Dynamic Range102dB, A-weighted
Signal-to-Noise Ratio-102dB, A-weighted
THD+N<0.003% (-90dB)
Crosstalk-100dB @ 1kHz
Nominal Output LevelBalanced: +4dBu
Nominal Output LevelUnbalanced: -10dBV
Maximum Output LevelBalanced: +10.2dBu, typical
Maximum Output LevelUnbalanced: +2.0dBV, typical
Output Impedance150 Ohm
Load Impedance600 Ohm minimum
Headphone Output 1 (at Maximum Volume; Into 100 Ohm load)
Frequency Response22Hz to 22kHz (+/-1dB)
Power into Ohms90 mW into 100 Ohms
THD+N<0.06% (-66dB)
Signal-to-Noise Ratio-90dB, A-weighted
Max Output Level into 100 Ohms+2.0dBV, typical
Output Impedance75 Ohm
Load Impedance32 to 600 Ohms
Weight1.3kg (2.87lbs)
Dimensions200 x 140 x 70 mm
Dimensions7.9” x 5.5” x 2.8”
  • Mac OS 10.8 - Mac OS 10.10
  • Windows XP - Windows 10
