Ultra 4 (ProDriveIII)
Capture your best performance with the iCON Pro Audio Ultra 4 USB 3.0 audio interface. We designed our latest 24-Bit 96/192KHz 2-In/2-Out audio interface to provide superior sonic quality, a low noise floor, and ultra fast processing in a rugged, compact, versatile desktop unit. Record two instruments at once through two high quality preamps each equipped with individual gain, phantom power, and LED level indicators to dial in your sound.
Plus the Ultra 4 comes complete with ProDriver, our innovative EFX rack, plug-in host, and virtual signal routing software. Run Ultra 4 in standalone mode or with your favorite DAW (Bitwig Studio 8-Track is also included). Host your guitar modeling and other VST plugins with ProDriver. Practice or just play without running your DAW. Process all of that through our new world-class D/A and A/D converters, and the Ultra 4 advances your performances with unsurpassed sharpness, clarity and focus.
FEATURES
- USB3.0 super-speed connectivity for ultra low latency
- 24-Bit 96/192KHz 2-In/2-Out USB Recording Interface
- High dynamic range and S/N ratio:
DAC: THD+N: -112dB; Dynamic Range: 120dB
ADC: THD+N: -110dB; Dynamic Range: 120dB - 2×2 analog I/O full duplex recording and playback
- 2 x ICON innovative unique mic/Line/Instrument preamps with individual gain control and phantom power switch
- 2 analog balanced inputs on 1/4” TRS jacks
- 2 analog balanced outputs on 1/4” TRS jacks
- 1 x 1 – 16 channel MIDI I/O
- Headphone output with individual volume control
- Bitwig Studio 8-Track DAW included
- iCON ProDriver software provided with internal virtual routing for inputs and outputs
- Powerful plugin hosting built in with iCON ProDriver software
- Flexible channel routing via the software control panel
- Direct monitoring switch for “Stereo, Mono and PC” with individual volume control
- Supports DirectSound, WDM and ASIO2.0
- Compatible with Mac OS (Intel-Mac) and Windows 7, 8& 10 (32-bit/64-bit)
- Full duplex, simultaneous record/playback
- Mixer-like layout and construction for easy operation and visual friendly
- Rugged aluminum construction
- Bitwig 8Track included
- Dotec audio plugins included
- Tracktion DAW Essentials Collection plugins included
- Kilohearts Toolbox plugins included
- Harrison 32c Vocal Intensity Processor plugin included
| Name | Spec |
| Line Inputs 1/2(balanced): | |
| Frequency Response | 22Hz to 22kHz (+/-0.1dB) |
| Dynamic Range | 117dB, A-weighted |
| Signal-to-Noise Ratio | -117dB, A-weighted |
| THD+N | -107dB |
| Crosstalk | -107dB@1kHz |
| Nominal Input Level | Balanced: +4dBu |
| Nominal Input Level | Unbalanced: -10dBV |
| Maximum Input level | Balanced: +10.2dBu, typical; |
| Maximum Input level | Unbalanced: +2.0dBV, typical |
| Input Impedance | 10K Ohms, typical |
| Adjustable Gain | > 50dB |
| Mic/Inst Inputs 1/2 (Balanced; at Minimum Gain): | |
| Frequency Response | 22Hz to 22kHz (+/-0.1dB) |
| Dynamic Range | 117dB, A-weighted |
| Signal-to-Noise Ratio | -117dB, A-weighted |
| THD+N | -107dB |
| Crosstalk | -107dB@1kHz |
| Maximum Input level | -3.8dBu, typical |
| Input Impedance | Inst in: 500K Ohms, typical; |
| Input Impedance | Mic in: 1.8K Ohms, typical |
| Adjustable Gain | > 50dB |
| Total Gain Range | +54dB |
| Line Outputs 1-2 (balanced): | |
| Frequency Response | 22Hz to 22kHz (+/-0.1dB) |
| Dynamic Range | 117dB, A-weighted |
| Signal-to-Noise Ratio | -117dB, A-weighted |
| THD+N | -107dB |
| Crosstalk | -107dB@1kHz |
| Nominal Output Level | Balanced: +4dBu, typical; |
| Maximum Output Level: | +10.2dBu; |
| Output Impedanc | 150 Ohm |
| Load Impedance | 600 Ohm minimum |
| Headphone Outputs: (at Maximum Volume; Into 100 Ohm load): | |
| Frequency Response: | 22Hz to 22kHz (+/-1dB) |
| Power into Ohms: | 90 mW into 100 Ohms |
| THD+N | <0.06% (-66dB) |
| Signal-to-Noise Ratio | -105dB, A-weighted |
| Max Output Level into 100 Ohms | +2.0dBV, typical |
| Output Impedance | 75 Ohm |
| Load Impedance | 32 to 600 Ohm |
| Weight | 0.641 KG（1.41lb） |
| Dimensions | 177mmx140mmx67mm |
| Dimensions | 6.97"(L)x5.51"(W)x2.64"(H) |
- Mac M2 CPU - Not Supported
- Mac OS X 10.11 El Capitan to Mac OS X 10.14 Mojave (Not compatible with later Mac operating systems)
- iOS 11 - iOS 14
- CPU/PC AMD
- Windows 7 - 11
