Platform X+
Expand your Platform M+ modular DAW control system by up to 32 channels using up to three Platform X+ units on most DAWs. Each Platform X+ houses eight touch-sensitive motorized channel faders with 10-bit resolution, eight dual function encoder knobs, and mute, solo, select, and record buttons. The iCON universal DAW mode on Platform X+ controls Cubase, Nuendo, Samplitude, Logic Pro, Studio One, Bitwig, Reason, Sonar, Digital Performer, Reaper, FL Studio, Adobe Audition, Ableton Live, and Pro Tools. Bitwig Studio 8-Track is included. Add the optional Platform D2 display to better view track names and parameters.
FEATURES
- 8-channel extender for Platform M+ (TM)
- Expandable to 32-channels control surface with 3 units of Platform X+ and a Platform M+
- Extremely compact, durable and versatile
- Customize the perfect setup with a variety of Platform extension modules
- 8 touch-sensitive motorized faders with 10-bit resolution
- 8 dual-functions encoder knobs (Rotate and enter)
- Illuminated buttons for each channel including Sel, Mute, Solo and Record
- Controls most popular DAWs including Cubase, Nuendo, Samplitude, Logic Pro, Bitwig, Studio One, Ableton Live, Pro Tools, Reason, Sonar, FL Studio, Digital Performer, Reaper and Adobe Audition
- iMapTM software included for easy mapping of MIDI functions
- Firmware upgrade available simply via USB connection and iMap software
- Class-compliant with Windows XP, Vista (32-bit), Windows 7 (32-bit & 64-bit),Windows 8 (32-bit 7 64-bit), Windows 10 and Mac OS X (IntelMac)
- USB 2.0 high speed connectivity
- Superior build quality and robust metal casing with Kensington lock port
- 12V/2.5A power adapter included
- Bitwig 8Track included
- Dotec audio plugins included
- Tracktion DAW Essentials Collection included
- Kilohearts Toolbox plugins included
- Harrison 32c Vocal Intensity Processor plugin included
*KNOWN ISSUES
Some DAWs limit the number of extenders that work with their software. The following list includes the maximum number of extenders you can use with the specified DAW.
*1 main unit + 7 extenders = 64 channels – Cubase/Nuendo, Studio One, Digital Performer, Logic Pro X, Mixbus
*1 main unit + 5 extenders = 48 channels – Ableton Live
*1 main unit + 3 extenders = 32 channels – Pro Tools, Bitwig, Reaper
*1 main unit + 1 extender = 16 channels – Reason, FL Studio, Cakewalk/Sonar, Samplitude
| Name | Spec |
| Connector | To computer: USB connector |
| Power supply | 12V2.5A DC (Outside negative inside positive) |
| Current consumption | 2.0A or less |
| Weight | 1.53kg (3.37lb) |
| Dimensions | 335(L) x 196(W) x 58(H)mm |
| Dimensions | 13.2”(L) x 7.7”(W) x 2.3”(H) |
- Setup procedure illustration - Ableton Live
- Setup procedure illustration - Audition
- Setup procedure illustration - Bitwig
- Setup procedure illustration - Cubase/Nuendo
- Setup procedure illustration - Logic ProX
- Setup procedure illustration - Pro Tools
- Setup procedure illustration - Reaper
- Setup procedure illustration - Reason
- Setup procedure illustration - Samplitude
- Setup procedure illustration - Sonar
- Setup procedure illustration - Studio One
- Setup procedure illustration (Use with Platform M+) - Cubase/Nuendo
- Setup procedure illustration (Use with Platform M+) - Ableton Live
- Setup procedure illustration (Use with Platform M+) - Logic ProX
- Setup procedure illustration (Use with Platform M+) - Pro Tools
- Setup procedure illustration (Use with Platform B+ and Platform M+) - Cubase/Nuendo
- Setup procedure illustration (Use with Platform B+ and Platform M+) - Ableton Live
- Setup procedure illustration (Use with Platform B+ and Platform M+) - Logic ProX
- Setup procedure illustration (Use with Platform B+ and Platform M+) - Pro Tools
- Intel CPU & Mac M1 CPU
- (Firmware is recognized on M1 Max, M1 Pro, M1 Ultra and AMD CPUs, however, you can only use Intel or M1 CPU to perform firmware update procedure)is recognized on M1 Max, M1 Pro and AMD CPUs, however, you can only use Intel or M1 CPU to perform firmware update procedure)
- Mac M2 CPU - Testing (Currently Not Supported)
- Mac OS X 10.11 El Capitan to macOS 12 Monterey
- macOS 13 Ventura - Testing (Currently Not Supported)
- iOS 11 - iOS 14
- Windows 7 - 11
