O3

MSRP

  • Dual golden painted 19mm capsule
  • Cardioids, omni and figure 8 patterns
  • True 20Hz to 20KHz frequency response with pronounced presence boost
  • Switch able high-pass filter and 10dB pad
  • Low cut
  • Very low self-noise
  • Exceptional low-frequency reproduction
  • High output level
  • High input SPL capability
  • Extremely uniform polar response
  • Classic character and rugged construction
  • Optional swivel mount
NameSpec
Acoustical elementDual back condenser capsule
Directional patternOmni directional / Cardioid / Figure-8
Frequency range40Hz to 18kHz
Sensitivity
Omni-36dBV/Pa
Cardioid-33dBV/Pa
Figure-8-36dBV/Pa
Rated Impedance200 Ohms
Min. load impedance1000 Ohms
SPL
Omni139dB
Cardioid136dB
Figure-8139dB
S/N ratio78dB
Dynamic range128dB
Power supply36-52V
Current consumption4mA
Weight0.6kg (1.3lbs)
Dimensions53mm(dia.) x 193mm(L)
Dimensions2.3”(dia.) x 7.6”(L)
