Uports4(ProDriveIII)

The ICON UPorts4 (ProDrive III) USB recording interface provides an audio input and output module with USB connectivity. Main features include:

  • 24-Bit 192KHz 4-In/4-Out USB Recording Interface
  • High dynamic range:
    DAC: Dynamic Range: 114dB
    ADC: Dynamic Range: 114dB
  • 2×2 analog I/O full duplex recording and playback
  • Dual Mic/Instrument preamps with individual gain control and phantom power switch
  • 2 analog outputs on 1/4” TRS jacks
  • S/PDIF I/O on RCA coaxial connectors
  • 1 x 1 – 16 channel MIDI I/O
  • Master volume control on the front panel
  • Direct monitor knob control on the top panel
  • 1 headphone output with assignable source and individual volume control
  • Flexible channel routing via the software control panel
  • ICON innovative ProDrive III plug-ins hosting rack is provided
  • Different ProDrive III plug-ins are provided
  • USB2.0 High Speed equipped and USB bus-powered
  • Supports DirectSound, WDM and ASIO2.0
  • Compatible with Mac OS (Intel-Mac), iOS 9 or above and Windows 7, 8 & 10 (32-bit/64-bit)
  • Full duplex, simultaneous record/playback
  • +5VDC power supply connector is equipped for external power supply when using with iOS
  • Rugged aluminum construction

Print

  • Mac OS X 10.11 El Capitan to Mac OS 13 Ventura
  • iOS 11 - iOS 14
  • Supports Intel, M1, M1 Max, M1 Pro, M1 Ultra, M2 and AMD processors
  • Windows 7 - 11
