Mobile 6

MSRP

24-Bit 96/192KHz 6-In/6-Out USB Recording Interface
4×4 analog I/O full duplex recording and playback
Dual MIC/Instrument preamps with individual gain control and phantom power switch
2 analogue line inputs on 1/4″ TRS jacks
4 analog outputs on 1/4” TRS jacks
S/PDIF I/O on RCA coaxial connectors
1 x 1 – 16 channel MIDI I/O
2- faders volume controls on the front panel
2 headphone output with channel 1/2 & 3/4 selectable switches and individual volume control
Flexible channel routing via the software control panel
4-channel faders plus one master channel fader
5 encoder knobs
Jog wheel shuttle for fast search and control
Illuminated buttons for each channel including Rec-enable, Solo and Mute
Illuminated “Channel/Bank” with “Up/Down” buttons for shifting channel by track or page
6 illuminated transport buttons including Play, Stop, Rec, Rewind, Fast forward and Loop
2-Illuminated Zoom keys for L/R & Up/Down
2-Illuminated Marker keys for Prev/Next & Up/Down
4-illuminated keys for Mixer, Edit, Save and Undo functions
2-illuminated “MK mode” buttons for shifting layer 1 & 2 in Mackie Control mode
2-illuminated “User mode” buttons for shifting layer 1 & 2 in user self define mode
Ex-Control connector for connecting up to 3 external control pedals (Optional EC-3 splitter cable and SPD-01 pedal are needed)
USB 2.0 high speed connectivity
Supports DirectSound, WDM and ASIO2.0
Class-compliant with Windows XP, Vista (32-bit), Windows 7 (32-bit & 64-bit), Windows 8 (32-bit & 64-bit)，Windows 10 and Mac OS X (IntelMac)
Full duplex, simultaneous record/playback
Mackie control built-in for Cubase, Nuendo, Samplitude, Logic Pro and Abelton Live.
Mackie HUI protocol built-in for Pro Tool.
Robust aluminum and metal casing with Kensington lock port

Name	Spec
Mic/Inst 1/2 Inputs (Balanced; at Minimum Gain)
Frequency Response	22Hz to 22kHz (+/-0.1dB)
Dynamic Range	100dB, A-weighted
Signal-to-Noise Ratio	-100dB, A-weighted
THD+N	<0.0048% (-90dB)
Crosstalk	-100dB @ 1kHz
Input Impedance	Inst in: 390K Ohms, typical
Input Impedance	Mic in: 1.8K Ohms, typical
Adjustable Gain	+45dB
Total Gain Range	+45dB
Line Inputs 3/4(balanced)
Frequency Response	22Hz to 22kHz (+/-0.1dB)
Dynamic Range	100dB, A-weighted
Signal-to-Noise Ratio	-100dB, A-weighted
THD+N	<0.0048% (-90dB)
Crosstalk	-100dB @ 1kHz
Nominal Output Level	Balanced: +4dBu
Nominal Output Level	Unbalanced: -10dBV
Maximum Output Level	Balanced: +10.2dBu, typical
Maximum Output Level	Unbalanced: +2.0dBV, typical
Input Impedance	10K Ohms, typical
Line Outputs 1-4 (balanced)
Frequency Response	22Hz to 22kHz (+/-0.1dB)
Dynamic Range	102dB, A-weighted
Signal-to-Noise Ratio	-102dB, A-weighted
THD+N	<0.003% (-90dB)
Crosstalk	-100dB @ 1kHz
Nominal Output Level	Balanced: +4dBu
Nominal Output Level	Unbalanced: -10dBV
Maximum Output Level	Balanced: +10.2dBu, typical
Maximum Output Level	Unbalanced: +2.0dBV, typical
Output Impedance	150 Ohm
Load Impedance	600 Ohm minimum
Headphone Outputs: 1 & 2 (at Maximum Volume; Into 100 Ohm load)
Frequency Response	22Hz to 22kHz (+/-1dB)
Power into Ohms	90 mW into 100 Ohms
THD+N	<0.06% (-66dB)
Signal-to-Noise Ratio	-90dB, A-weighted
Max Output Level into 100 Ohms	+2.0dBV, typical
Output Impedance	75 Ohm
Load Impedance	32 to 600 Ohms
General
Power supply	12V/DC (1A)
Current consumption	100mA or less
Weight	kg (3.96lb)
Dimensions	382(L) X 180(W) X 53(H)
Dimensions	15.0”(L) x 7.1”(W) x 2.1”(H)
