● Powerful controller is equipped and easy setup with Mackie Control and HUI protocol
● 24-Bit 96/192KHz 2-In/2-Out USB Recording Interface
● 2×2 analog I/O full duplex recording and playback
● 1 mic input with individual gain control
● 2 analog inputs and 2 analog outputs on 1/4” TRS jacks
● Backlit LED touch fader reacts in real-time with DAW. Synchronize automatically
with different channel value when switching between channels
● Dual function encoder knob (Enter & rotate)
● 11-segment LED surrounding the encoder to indicate the rotating position
● Velocity-sensitive piano style keyboard
● Modulation and Pitch jog-wheel
● 3-segment LED screen
● 18 assignable LED backlit buttons
● Illuminated channel buttons including Rec-enable, Solo and Mute
● 6 illuminated transport buttons including Play, Stop, Rec, Rewind, Fast forward and Loop
● Single Transpose button use combine with keyswitch to shift pitch effectively.
● Octave up/down buttons
● Multi velocity curves available for selection (Key and Pads)
● Midi output jack
● 1 headphone output with assignable source and individual volume control
● Expression & sustain pedal TRS connectors
● Flexible channel routing via the software control panel
● Supports DirectSound, WDM and ASIO2.0
● Full duplex, simultaneous record/playback
● Mackie control built-in for Cubase, Nuendo, Samplitude, Logic Pro, Bitwig, Reason, Reaper, Studio One and Ableton Live
● Mackie HUI protocol built-in for Pro Tool
● Driver built-in for Cubase, Nuendo, Bitwig and Reason for plug and play
● iMapTM software included for easy mapping of MIDI functions
● Firmware upgrade available simply via USB connection and iMap software
● Compatible with Mac OS (Intel-Mac) and Windows 7 (32-bit/64-bit) & Windows 8 (32-bit/64-bit),Windows 10 (32-bit & 64-bit)
● USB 2.0 high speed connectivity
● Robust metal casing with Kensington lock port
| Name | Spec |
| Connector | |
| USB | USB connector (standard type) |
| Sustain & Expression | 2x1/4” TS connectors |
| MIDI I/O | 5-pin Din connector |
| Line in (L/R) | 2x1/4” TS connectors |
| Line Out (L/R) | 2x1/4” TS connectors |
| Mic in | XLR balanced connector |
| Headphone out | 1/4” stereo connector |
| General | |
| Power supply | 7V/1A DC |
| Current consumption | 500mA or less |
| Weight | 2.45kg 5.4(lb) |
| Dimensions | 530(L)x189(W)x77(H)mm |
| Dimensions | 21"(L)x7.44"(W)x3"(H) |
| Mic Input (at Minimum Gain) | |
| Frequency Response | 22Hz to 22kHz (+/-0.1dB) |
| Dynamic Range | 93dB, A-weighted |
| Signal-to-Noise Ratio | -93dB, A-weighted |
| THD+N | <0.0061% (-90dB) |
| Crosstalk | -87dB @ 1kHz |
| Input Impedance | Mic in: 1.8K Ohms, typical |
| Adjustable Gain | +34dB |
| Total Gain Range | +50dB |
| Line Inputs 1/2 (Unbanced) | |
| Frequency Response | 22Hz to 22kHz (+/-0.1dB |
| Dynamic Range | 100dB, A-weighted |
| Signal-to-Noise Ratio | -100dB, A-weighted |
| THD+N | <0.0061% (-90dB) |
| Crosstalk | -100dB @ 1kHz |
| Nominal Input Level | Unbalanced: +4dBV, typical; |
| Maximum Input level | Unbalanced: +11dBV, typical; |
| Input Impedance | 10K Ohms, typical |
| Line Outputs 1/2 (Unbanced) | |
| Frequency Response | 22Hz to 22kHz (+/-0.1dB |
| Dynamic Range | 102dB, A-weighted |
| Signal-to-Noise Ratio | -102dB, A-weighted |
| THD+N | <0.003% (-90 dB) |
| Crosstalk | -100dB @ 1kHz |
| Nominal Output Level | Unbalanced: +4dBV, typical; |
| Maximum Output Level | +11dBV, typical; |
| Output Impedance | 150 Ohm |
| Load Impedance | 600 Ohm minimum |
| Headphone Output: (at Maximum Volume; Into 100 Ohm load) | |
| Frequency Response | 22Hz to 22kHz (+/-0.1dB |
| Power into Ohms | 90 mW into 100 Ohms |
| THD+N | <0.06% (-66dB) |
| Signal-to-Noise Ratio | -90dB, A-weighted |
| Max Output Level into 100 Ohms | +2.0dBV, typical |
| Output Impedance | 75 Ohm |
| Load Impedance | 32 to 600 Ohms |
