Duo44 Live

USB Audio Interface for Computers, Tablets, and Smartphones

The iCON Pro Audio Duo44 Live USB recording interface provides an audio input and output module as well as analog & digital connectivity with any Smart mobile device for live streaming applications.

The Icon Pro Audio Duo 44 Live is ideal for musicians, producers, and performers who want to incorporate a mobile device into their setup. Featuring simultaneous desktop and mobile connectivity, it enables you to stream audio from your computer directly to your mobile device.



  Icon Pro Audio Duo44 Live Audio InterfaceCreate the perfect recordings on your computer or mobile device with high-end analog-to-digital converters. High dynamic range ensures your performances are captured in the greatest of detail. Hook up a condenser or dynamic microphone, and a guitar or bass to lay down your ideas. Connect speakers or headphones and use Direct Monitoring to hear yourself with zero latency while recording.

Dual connectivity designed to enhance your mobile live streams, podcasts, or videos. From a one man show to a full live band, broadcast your mix at ultra low-latency directly to your mobile device.

iCON’s ProDriver software lets you redirect audio from any source on your computer and hosts your favorite AU, VST, VST3 or Direct X plugins without a DAW. Save your plugin chains as presets and recall them during your session.

  • Pristine Audio: 4-in/4-out USB recording interface housed in a rugged aluminum chassis with premium converters for world-class 24-bit/192kHz recording and mixing with ultra-low latency

  • Live Streaming: simultaneous desktop and mobile connectivity enables to live stream audio from the computer to a mobile device with analog (TRRS) and digital (USB-C) connections for any smartphone, adjustable onboard inputs level and monitoring

  • Compatibility: Fast USB 2.0 connection (bus-powered) is compatible with Mac and PC

  • Got MIDI? Connect MIDI devices using onboard MIDI I/O

  • Virtual Plug-In Rack: iCON ProDriver software routes audio to and from any source on the computer and enables hosting of AU, VST, VST3 or Direct X plugins without a DAW. Save plugin chains as presets and recall them during a session.

  • Bitwig Studio 8-Track DAW is also included

Main features include:

  • 24-Bit 192KHz 2 mic-In/2 inst-In, 2-Out USB Recording Interface
  • Professional & Hi-end grade DA/AD provides high dynamic range
    • DAC: Dynamic Range: 114dB
    • ADC: Dynamic Range: 114dB
  • Supports Mac/PC connectivity simultaneously with SmartDevice
  • Live session possible with audio signal processing via ProDriver4 virtual plug-in rack
  • 4×4 analog I/O full duplex simultaneous recording and playback
  • Compatible with iOS and Android Digital I/O jack (Type C) & Analog I/O jack (3.5mm stereo TRRS) for direct connection with smartphone, tablet or other device
  • Mic/Instrument preamps with individual gain control and phantom power switch
  • 2 analog outputs on 1/4” TRS jacks
  • Monitor volume control knob on the top panel
  • Direct monitor button control on the top panel
  • 1 headphone output with assignable source and individual volume control
  • Flexible channel routing via the ProDriver4 software control panel
  • ICON ProAudio developed ultra low latency ProDriver4™driver is provided
  • ICON ProAudio innovative and user friendly plug-in hosting rack software is built-in with ProDriver4™
  • USB2.0 High Speed equipped and USB bus-powered
  • Supports DirectSound, WDM and ASIO2.0
  • Compatible with mac OS (Intel-Mac) 10.11 and later, iOS 9 or above, Andriod  and Windows 7, 8 & 10 (32-bit/64-bit)
  • +5VDC power supply connector is equipped for external power supply when using with iOS
  • Rugged aluminum construction
  • Bitwig 8Track included
  • Dotec audio plugins included
  • Tracktion DAW Essentials Collection plugins included
  • Kilohearts Toolbox plugins included
  • Harrison 32c Vocal Intensity Processor plugin included
NameSpec
Mic1 / 2 Inputs (at Minimum Gain):
Frequency Response22Hz to 22kHz (+/-0.1dB)
Dynamic Range114dB, A-weighted
Signal-to-Noise Ratio-114dB, A-weighted
THD+N-100dB
Crosstalk-97dB@1kHz
Input ImpedanceMic in: 1.8K Ohms, typical
Adjustable Gain+34dB
Total Gain Range+50dB
Inst1 / 2 Inputs (at Minimum Gain):
Frequency Response22Hz to 22kHz (+/-0.1dB)
Dynamic Range114dB, A-weighted
Signal-to-Noise Ratio-114dB, A-weighted
THD+N-100dB
Crosstalk-97dB @ 1kHz
Input ImpedanceInst in: 500K Ohms, typical;
Adjustable Gain+39dB
Total Gain Range+39dB
Line Outputs 1/2 (Unbanced):
Frequency Response22Hz 22kHz (+/-0.1dB)
Dynamic Range114dB, A-weighted
Signal-to-Noise Ratio-114dB, A-weighted
THD+N-100 dB
Crosstalk-97dB @ 1kHz
Nominal Output LevelUnbalanced: +4dBV, typical;
Maximum Output Level+11dBV, typical;
Output Impedance150 Ohm
Load Impedance600 Ohm minimum
Headphone Outputs: 1 & 2 (at Maximum Volume; Into 100 Ohm load):
Frequency Response22Hz to 22kHz (+/-1dB)
Power into Ohms90 mW into 100 Ohms
THD+N<0.06% (-66dB)
Signal-to-Noise Ratio-100dB, A-weighted
Max Output Level into 100 Ohms+2.0dBV, typical
Output Impedance75 Ohm
Load Impedance32 to 600 Ohms
Weight0.943 KG (2.08lb)
Dimensions165mmx185mmx58mm
Dimensions6.5"(L)x7.28"(W)x2.28"(H)
  • Mac OS X 10.11 El Capitan to Mac OS 13 Ventura
  • Android
  • iOS 11 - iOS 14
  • Supports Intel, M1, M1 Max, M1 Pro, M1 Ultra, M2 and AMD processors
  • Windows 7 - 11
