Cube4Nano (Pro-DriveIII)

Record anywhere, anytime, even with your iPhone, using the Icon Pro Audio Cube4Nano (ProDrive III) USB 2.0 audio interface. We upgraded this popular 24-Bit 96/192KHz 2-In/2-Out audio interface with a brand new JCT 3.0 audio processing chip to increase conversion quality, lower the noise floor, and increase processing speeds. Each of the two mic preamps comes equipped with individual gain, and phantom power, and the unit offers 2 analog TRS outputs, S/PDIF I/O and MIDI I/O for maximum versatility in this rugged, highly portable unit.

The Cube4Nano (ProDrive III) also features ProDrive III, our innovative plug-in host and virtual signal router. Run it either in standalone mode or with your favorite digital audio workstation. We also included a suite of music production plug-ins for advanced processing.

FEATURES

  • 24-Bit 96/192KHz 4-In/4-Out USB Recording Interface
  • High dynamic range and S/N ratio:
    DAC: THD+N: -100dB; Dynamic Range, S/N: 114dB
    ADC: THD+N: -98dB;   Dynamic Range, S/N: 112dB
  • 2×2 analog I/O full duplex recording and playback
  • ICON “ProDrive III” provided with internal virtual rounting for inputs and outputs
  • Powerful  ProDrive III hosting rack built in
  • Flexible channel routing via the software control panel (Windows only)
  • Different  ProDrive III plug-ins are provided
  • Dual MIC/Instrument preamps with individual gain control and phantom power switch
  • 2 analog outputs on 1/4” TRS jacks
  • S/PDIF I/O on RCA coaxial connectors
  • 1 x 1 – 16 channel MIDI I/O
  • Master volume control on the front panel
  • 1 headphone output with assignable source and individual volume control
  • Direct monitoring switch for “Stereo, Mono and PC” with individual volume control
  • USB2.0 High Speed equipped and USB bus-powered
  • Supports DirectSound, WDM and ASIO2.0
  • Compatible with Mac OS (Intel-Mac), iOS and Windows  7,8 & 10 (32-bit/64-bit)
  • Full duplex, simultaneous record/playback
  • +5V DC power supply connector is equipped for external power supply when using with iOS
  • Rugged aluminum construction

Print

  • Mac OS X 10.11 El Capitan to Mac OS 13 Ventura
  • iOS 11 - iOS 14
  • Supports Intel, M1, M1 Max, M1 Pro, M1 Ultra, M2 and AMD processors
  • Windows 7 - 10
