VH4

FEATURES

• 24-Bit 96/192KHz 4-In/4-Out USB Recording Interface
• High dynamic range and S/N ratio:
  DAC: THD+N: -100dB; Dynamic Range, S/N: 114dB
  ADC: THD+N: -98dB;   Dynamic Range, S/N: 112dB
• 2×2 analog I/O full duplex recording and playback
• ICON “ProDrive III” provided with internal virtual rounting for inputs and outputs
• Powerful  ProDrive III hosting rack built in
• Flexible channel routing via the software control panel (Windows only)
• Different  ProDrive III plug-ins are provided
• Dual MIC/Instrument preamps with individual gain control and phantom power switch
• 2 analog outputs on 1/4” TRS jacks
• S/PDIF I/O on RCA coaxial connectors
• 1 x 1 – 16 channel MIDI I/O
• Master volume control on the front panel
• 1 headphone output with assignable source and individual volume control
• Direct monitoring switch for “Stereo, Mono and PC” with individual volume control
• USB2.0 High Speed equipped and USB bus-powered
• Supports DirectSound, WDM and ASIO2.0
• Compatible with Mac OS (Intel-Mac), iOS and Windows  7,8 & 10 (32-bit/64-bit)
• Full duplex, simultaneous record/playback
• +5V DC power supply connector is equipped for external power supply when using with iOS
• Rugged aluminum construction
