● 3-in / 3-out MIDI interface (48×48 MIDI channels)
● Supports multiple platforms with MultiPlatTM driver (Windows only)
● MultiPlatTM driver available for 32-bit and 64-bit Windows platforms
● USB 2.0 for high-speed connection
● Plug & play for Mac and Window platforms
● Class-compliant with Windows XP, Vista (32-bit), Windows 7 (32-bit/64-bit) and Mac OS X
● No IRQ, I/O address or DMA channel setup
● Perfect MIDI timing
● MIDI-in and MIDI-out activity indicators for each port
● USB bus powered, no external power supply required
Name | Spec |
Connector | |
USB | USB 2.0 connector (standard type) |
MIDI Inputs | 3 x Din 5 female MIDI connectors |
MIDI Outputs | 3 x Din 5 female MIDI connectors |
Signal Indicator | |
USB signal | 1 x White color LED |
MIDI Inputs | 3 x Green color LEDs |
MIDI Outputs | 3 x Red color LEDs |
General | |
Power supply | USB bus-powered |
Current consumption | 100mA or less |
Weight | 0.88kg (1.9lbs) |
Dimensions | 165 x 165 x 50 mm |
Dimensions | 6.5” x 6.5” x 2.0” |
