InSpire 6 G2

● ICON innovative “VirtualPort TM” matrix technology provides 4 independent USB output for Multi-software operation simultaneously
● Key switch and pads allow multi-assignment & simultaneous operation on multi- software
● The powerful controller is equipped and easily set up with Mackie Control and HUI protocol
● Semi-weighted velocity-sensitive piano style keyboard
● Combined pitch/modulation joystick
● 8 x dual function encoder knobs (Enter & rotate)
● 8+1 assignable faders
● 12 integrated velocity-sensitive trigger pads send MIDI notes or control data
● X/Y touchpad
● “Hold”, “Pad Roll” & “Key Roll” feature buttons are equipped for Pad & Key rolling effect when using with the touchpad
● Large backlit LCD to display channel name, control values etc. for each channel
● 62 assignable buttons
● Jog wheel shuttle for fast search and control
● Illuminated buttons for each channel including Rec-enable, Solo, Mute and Select
● 6 illuminated transport buttons including Play, Stop, Rec, Rewind, Fast forward and Loop
● Illuminated zoom key with 4 direction keys
● Single Transpose button use combines with key switch to shift pitch effectively
● Multi velocity curves available for selection (Key and Pads)
● 1 x 1 16-channels MIDI I/O
● Expression & sustain pedal TRS connectors
● Expansion slot for ICON’s “Synth” series synthesizer module card
● Expansion slot for ICON’s “Satellite” series USB audio interface card
● Mounting holes equipped for an optional iPad holder
● Class-compliant with Windows XP, Vista (32-bit), Windows 7 (32-bit & 64-bit), Windows 8 (32-bit & 64-bit) ,Windows 10 (32-bit & 64-bit) and Mac OSX (IntelMac)
● USB 2.0 high speed connectivity
● Mackie control built-in for Cubase, Nuendo, Samplitude, Logic Pro and Abelton Live
● Mackie HUI protocol built-in for Pro Tool
● User self-define mode (MIDI Learn) for other DAW such as Sonar
● Firmware upgrade available simply via USB connection and iMap software
● Template labels are included for difference popular DAW such as Cubase, Nuendo, Samplitude, Logic Pro and Abelton Live
● Robust aluminum and metal casing with Kensington lock port
